2-Megapixel MIPI Camera Module – 3P+IR FF Fixed-Focus Low-Power Module with Customizable Dimensions

Product Description

This MIPI camera module features a gold-pin connector interface and offers 2-megapixel fixed-focus performance, specifically designed for smartphones, tablets, and other lightweight, portable smart devices.

Equipped with a 1/5-inch photosensitive sensor featuring 1.75 μm fine pixel cells, it delivers 1600×1200 UXGA high-definition images at a stable 30 frames per second. The module employs a high-spec 3P+IR optical lens with an F2.2 large aperture and 74.3° moderate field of view, ensuring ample light intake for clear, bright images in low-light conditions, while infrared fill light enhances night vision clarity.

Featuring a gold-finger contact interface design, the device ensures stable and reliable plug-and-play assembly while eliminating complex welding steps, significantly simplifying the overall assembly process and enhancing production efficiency. Equipped with a high-speed MIPI differential transmission interface, it offers strong interference resistance and smooth, stable image transmission. Operating at UXGA 30fps, it consumes only 120 mW of power, balancing high-definition imaging performance with minimal battery drain.

Supports stable operation across a wide temperature range of 20°C to 70°C, suitable for various complex applications. With dimensions of just 14.9×12.2 mm, it is compact and lightweight, and offers size customization to perfectly fit the structural designs of ultra-thin devices.

Application scope

Custom services for mobile phone secondary cameras, tablet front-facing secondary cameras, and smart learning devices.

Custom Service

If you need camera modules with different lenses or sizes, please contact us.

Specifications
